Device Features

1. Supports external IO signal control and standard Modbus-RTU communication protocol for remote parameter reading/writing and light switching.

2. Supports independent and synchronous control modes:

? Independent Mode: Each of the four channels operates separately without interference.

? Synchronous Mode: All four channels start and stop simultaneously.

3. Provides three operation modes:

a. Fixed-Auto Mode: The device cures according to the preset exposure time and automatically shuts down after countdown.

b. Fixed-Manual Mode: Manually start curing via touch screen switch or external IO control; records exposure duration after shutdown.

c. Stepped Mode: Supports up to 20 exposure steps with a maximum of 255 cycles. Each step's time and power can be set independently:

? When time is set to 0, the system skips to the next step immediately.

? When power is set to 0 and time ≥1, the light turns off and delays for the set time before proceeding to the next step.

4. Features: Digital dimming (0-100%), exposure history query, and alarm functions for abnormalities.

Light Source Characteristics

? High Efficiency & Energy Saving

UVLED's concentrated output spectrum and high electro-optical conversion rate ensure energy efficiency, fast curing, and improved productivity.

? Wide Applicability

As a cold light source with minimal infrared heat radiation, UVLED prevents thermal stress and deformation, making it suitable for curing heat-sensitive materials.

? Extended Lifespan

Long service life reduces equipment costs. Instant on/off operation eliminates warm-up time, and switching frequency does not affect longevity.

? Environmentally Friendly

RoHS compliant and mercury-free.
